Jumbo / Jumbo Powerstation
- Made of aluminium profil 80 x 80 mm
- With one or two integrated sockets SCHUKO (alt. CH T13),
- Height 170mm or 230 mm
- Feed cable 1.500 mm, three-conductor, free ends
- Connection through the worktop plate.
- Mounting plate 120 x 120 x 3 mm
- Fixation through the worktop with screw M10
- Both finishes are also available without plugs.
- Glass fixation with additional fixation set (total height + 3 mm)
| Type | Art. No. |
|---|---|
| Jumbo (with 1 or 2 sockets) | |
| Jumbo stainless steel 230 mm | 20.033.27 |
| Powerstation stainless steel 2x SCHUKO 230 mm | 20.032.27 |
| Powerstation stainless steel 2x CH T13 230 mm | 20.032.41 |
| Jumbo black matt 170 mm | 20.033.13-170 |
| Jumbo stainless steel 170 mm | 20.033.27-170 |
| Powerstation black mat 1x SCHUKO 170 mm | 20.032.13-170 |
| Powerstation stainless steel 1x SCHUKO 170 mm | 20.032.27-170 |
| Powerstation stainless steel 1x CH T13 170 mm | 20.032.41-170 |
| Glass fixation set, stainless steel | 25.006.15 |
